Property

Description

Name/Identifier

Name/Identifier will be the unique identity of the cell and can be used to set the value in the cell.


Select the field from the dropdown option which is defined for Image in the database. The image name in the Database should be same as the name of Image file uploaded. To know more about uploading an image Click here.

Note: The main text will be left-aligned if the user doesn’t specify any image.

Main Text

Select the database field from the dropdown which user wants to display as the Main text or set the primary data or Main text manually.

Background Color

User can set the background color of the cell.

Accessory Type

Select Accessory Type which is displayed as button on the right side of the cell.

The options available are : "Indicator", "Button" or "none".

On Tap Accessory Button

On Tap Accessory Button is a function/event attached to the cell that acts as trigger to launch the actions.

To know more about Functions Click here.

The function/event will occur when the user clicks only on the provided accessory button.

On Tapping Row

On Tapping Row is the function/event attached to the cell that  will occur when the user clicks anywhere on the cell.

On Flick Cell (Right to Left)

On Flick Cell is the function/event attached to the cell that will occur when the user flicks (slight movement of UI on touch) the Cell from Right to Left.

On Flick Cell (Left to Right)

On Flick Cell is the function/event attached to the cell that will occur when the user flicks (slight movement of UI on touch) the Cell from Left to Right.
